MD-60 - CUI DEVICES - CONN PLUG MALE MINI DIN 6P SLDR | |
Packaging | Bag |
Features | Backshell, Strain Relief |
Connector Type | Plug, Male Pins |
Color | Black |
Voltage Rating | 100VAC, 12VDC |
Current Rating (Amps) | 1A, 2A |
Mounting Type | Free Hanging (In-Line) |
Shielding | - |
Number of Positions | 6 |
Orientation | Keyed |
Shell Size - Insert | Mini DIN |
Operating Temperature | -20°C ~ 105°C |
Fastening Type | Push-Pull |
Termination | Solder, Crimp Pin Adapter Available |
Ingress Protection | - |
Cable Opening | - |
Material Flammability Rating | - |
Mounting Feature | - |
Shell Size, MIL | - |
Contact Finish - Mating | Silver |
Shell Material | Polyacrylonitrile Butadiene Styrene (ABS) |
Shell Finish | - |
Primary Material | Plastic |
