0708150.UR
150 A 125 V Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, J-Lead
| 0708150.UR - LITTELFUSE INC. - 714 NANO FUSE SERIES | |
| Mounting Type | Surface Mount |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Current Rating (Amps) | 150 A |
| Voltage Rating - DC | 125 V |
| Response Time | Slow Blow |
| Package / Case | 2-SMD, J-Lead |
| Breaking Capacity @ Rated Voltage | 3kA |
| Melting I²t | 18350.0 |
| Approval Agency | CE, cURus, TUV, UKCA |
| Operating Temperature | -55°C ~ 125°C |
| Color | - |
| Size / Dimension | 0.453" L x 0.394" W x 0.295" H (11.50mm x 10.00mm x 7.50mm) |
