PEC07DAAN - SULLINS CONNECTOR SOLUTIONS - CONN HEADER VERT 14POS 2.54MM | |
Packaging | Bulk |
Features | - |
Connector Type | Header, Breakaway |
Voltage Rating | - |
Current Rating (Amps) | 3A |
Mounting Type | Through Hole |
Number of Positions | 14 |
Number of Rows | 2 |
Style | Board to Board or Cable |
Operating Temperature | -65°C ~ 125°C |
Contact Type | Male Pin |
Fastening Type | Push-Pull |
Number of Positions Loaded | All |
Termination | Solder |
Ingress Protection | - |
Material Flammability Rating | UL94 V-0 |
Contact Material | Phosphor Bronze |
Insulation Color | Black |
Pitch - Mating | 0.100" (2.54mm) |
Contact Finish - Mating | Tin |
Contact Finish Thickness - Mating | 100.0µin (2.54µm) |
Contact Finish - Post | Tin |
Contact Shape | Square |
Contact Length - Post | 0.120" (3.05mm) |
Insulation Height | 0.100" (2.54mm) |
Shrouding | Unshrouded |
Overall Contact Length | 0.450" (11.43mm) |
Insulation Material | Polybutylene Terephthalate (PBT) |
Row Spacing - Mating | 0.100" (2.54mm) |
Contact Length - Mating | 0.230" (5.84mm) |
