| B33331I6305J080 - EPCOS - TDK ELECTRONICS - 3UF 450V AL 30*55 S2 2+2 | |
| Capacitance | 3 µF |
| Tolerance | ±5% |
| Voltage Rating - AC | 450V |
| Voltage Rating - DC | - |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 2.244" (57.00mm) |
| Termination | Quick Connect - 0.250" (6.3mm) |
| Lead Spacing | - |
| Applications | Motor Run |
| Ratings | - |
| Features | - |
