| TUHS25F12 - COSEL USA, INC. - AC/DC CONVERTER 12V 25W | |
| Type | Enclosed |
| Number of Outputs | 1 |
| Voltage - Input | 85 ~ 264 VAC, 120 ~ 370 VDC |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 2.1A |
| Power (Watts) | 25 W |
| Applications | ITE (Commercial) |
| Features | Universal Input |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Efficiency | 88% |
| Mounting Type | Through Hole |
| Package / Case | 6-DIP Module |
| Size / Dimension | 1.42" L x 1.00" W x 0.65" H (36.1mm x 25.4mm x 16.5mm) |
| Approval Agency | CE, cURus |
