68611614422
16 Position FPC Connector Contacts, Bottom 0.039" (1.00mm) Surface Mount, Right Angle
| 68611614422 - WÜRTH ELEKTRONIK - CONN FPC BOTTOM 16POS 1MM R/A | |
| Packaging | Cut Tape (CT) |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Contact Finish | Tin |
| Voltage Rating | 125V |
| Mounting Type | Surface Mount, Right Angle |
| Number of Positions | 16 |
| Pitch | 0.039" (1.00mm) |
| Operating Temperature | -25°C ~ 85°C |
| Termination | Solder |
| Height Above Board | 0.118" (3.00mm) |
| Locking Feature | Slide Lock |
| Material Flammability Rating | UL94 V-0 |
| Actuator Material | Polyphenylene Sulfide (PPS) |
| Contact Material | Phosphor Bronze |
| FFC, FCB Thickness | 0.29mm ~ 0.34mm |
| Housing Material | Polyphenylene Sulfide (PPS) |
| Cable End Type | Tapered |
| Flat Flex Type | FPC |
| Connector/Contact Type | Contacts, Bottom |
