7447709222
2.2 mH Shielded Drum Core, Wirewound Inductor 530 mA 3.75Ohm Max Nonstandard
| 7447709222 - WÜRTH ELEKTRONIK - FIXED IND 2.2MH 530MA 3.75OHM SM | |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 2.2 mH |
| Tolerance | ±20% |
| Current Rating (Amps) | 530 mA |
| Current - Saturation (Isat) | 750mA |
| Shielding | Shielded |
| DC Resistance (DCR) | 3.75Ohm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 660kHz |
| Ratings | AEC-Q200 |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 1 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.472" L x 0.472" W (12.00mm x 12.00mm) |
| Height - Seated (Max) | 0.394" (10.00mm) |
