TBP04R1-500-09BE
9 Position Terminal Block Header, Male Pins, Shrouded (2 Side) 0.197" (5.00mm) 90°, Right Angle Through Hole
| TBP04R1-500-09BE - CUI DEVICES - 2~24 POLES, PLUGGABLE, RECEPTACL | |
| Packaging | Box |
| Features | - |
| Color | Blue |
| Mounting Type | Through Hole |
| Number of Positions | 9 |
| Pitch | 0.197" (5.00mm) |
| Type | Header, Male Pins, Shrouded (2 Side) |
| Operating Temperature | -40°C ~ 105°C |
| Termination Style | Solder |
| Current - IEC | 10A |
| Number of Levels | 1 |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Positions Per Level | 9 |
| Header Orientation | 90°, Right Angle |
| Plug Wire Entry | - |
| Contact Mating Finish | Tin |
| Current - UL | 15 A |
| Voltage - IEC | 400 V |
| Voltage - UL | 300 V |
