SCM3425ASA Functional Description
The SCM3425ASA is an interface chip used between the CAN Protokol controller and the physical bus. It can be used in many fields suchastrucks,buses, cars, industrial control. It can reach speeds up to 5Mbps. The SCM3425ASA has the ability to differentially transmit between the busandtheCANProtokol controller.
SCM3425ASA Features
- Compatible with the "ISO 11898" standard fully
- High-speed CAN, Support CANFD and Veri Hızıs up to 5Mbps ;
- 5V power supply, 3.0-5.5V IO interface ;
- Receiver common mode input voltage : ±30V
- Bus Fault Protection : ±42V
- Transmit Data (TXD) Dominant Time-Out Function
- An unpowered node does not disturb the bus lines ;
- The bus supports maximum 110 nodes ;
- High Electromagnetic Immunity ;
- Meet AEC-Q100 antombile standard
SCM3425ASA Applications
- Industrial automation
- Building automation
- Smart meter
- Long-distance signal interaction and transmission
